Economy Meets Style.

The MOSAIC+ Modular Panel Series is a pre-engineered modular cassette-style panel. Manufactured with the latest in CNC manufacturing technology, MOSAIC+ offers an economic cladding solution with design flexibility for even the most complex panel applications.

Complex Designs. Simple Install.

This rainscreen panel features an interlocking dry joint design that allows for an efficient installation.

Create dramatic aesthetics and plane changes by combining Mosaic+ Flat panels with Mosaic+ Dimensional and Tapered Series.

The wall is your canvas!

Advantages & Benefits

Non-Combustible	Mosaic – Stacked – Running Bond Panel Grids
100% Recyclable	Flat – Dimensional – Tapered panel options
Concealed fasteners	Multiple panel depths (1.5”-2”-3”-4”)
No gaskets	Mix and match depths and sizes
Coil Coated Aluminum for Consistency & Coverage	Large panel formats
Embossed or Perforated textures available	Easy to cut and install in the field
20-Year Finish Warranty on most painted finishes	Full fabrication packages available
2-Year Workmanship Warranty	Made in the USA

Testing

ASTM E-330	AAMA 508^*
ASTM E-283^*	AAMA 509
ASTM E-331^*	NFPA 285 Compliant

^{* Coming Soon}

Facade Attachment Solutions.

This product can integrate with several engineered, tested, and warranted façade attachment solutions that meet and exceed the ASHRAE 90.1, 2010 standard regarding thermal bridging. NEXGEN can provide a complete system upon request.

Contact NEXGEN to learn more about the MOSAIC+ Modular Panel Series.
